100Cr2 1.3501 Cold Working Tool Steel
100Cr2 1.3501 Cold Working Tool Steel
1 100Cr2 Introduction:
Low alloyed cold working tool steel.
We can provide more services:
1、Hardening and tempering
2、Vacuum heat treatment
3、Polished bright surface
4、Milling bright surface
5、CNC machine
6、Deep drilling
7、Cut into small pieces
8、Make it closer to the mold
Welcome to inquiry price from drawing
Cutting:
Precision cutting to standard dimensions
Custom cutting according to client specifications
Surface Grinding/Polishing:
Thickness tolerance: -0 to +0.1mm
Flatness: 0.01/100mm
Surface roughness: Ra ≤1.6 or Rz ≤6.3
2 100Cr2 Applications:
It can be used as structural steel for manufacturing of balls, rollers and needles for bearings up to 10 mm of thickness. This steel grade can be used also as cold working tool steel.
3 Quality Standard:
DIN 17230-1980 Ball and Roller Bearing Steels
ASTM A29 Standard Specification Steel Bars, Carbon and Alloy, Hot-Wrought, General Requirements
4 All Grades Comparison:
| ASTM | Material No. | EN |
|---|---|---|
| 50100 | 1.3501 | 100Cr2 |
5 100Cr2 Chemical Composition(%)
| Steel Grade | C | Si | Mn | P | S | Cr | Ni | Cu |
|---|---|---|---|---|---|---|---|---|
| 100Cr2/1.3501 | 0.90-1.05 | 0.15-0.35 | 0.25-0.45 | 0.030 max | 0.025 max | 0.40-0.60 | 0.30 max | 0.30 max |
| 50100 | 0.98-1.10 | 0.15-0.35 | 0.25-0.45 | 0.030 max | 0.025 max | 0.40-0.60 | 0.30 max | 0.30 max |
6 100Cr2 HEAT TREATMENT:
- FORGING:</emHot forming temperature: 1100-850oC.
- SOFT ANNEALING: Heat to 730-760oC, cool slowly. This will produce a maximum Brinell hardness of 207.
- STRESS RELIEVING: Stress relieving to remove machining stresses should be carried out by heating to approx. 600-650oC, holding for 1-2 hours at heat, followed by air cooling. This operation is performed to reduce distortion during heat treatment.
- HARDENING: Harden from a temperature of 780-810oC, 820-850oC followed by water or oil quenching. Hardness after quenching is about 60 HRC.
- TEMPERING: Tempering temperature: 150-180 oC.
7 Mill′s test certificate:
EN 10204/3.1 with all relevant data reg. chem. composition, mech. properties and results of testing.
