1.2661, 38CrCoWV18-17-17, Hot Work Tool Steel
| Grade : | 38CrCoWV18-17-17 |
| Number: | 1.2661 |
| Classification: | Hot-work tool steel |
| Standard: | EN ISO 4957: 2000 Tool steels |
Cutting:
Precision cutting to standard dimensions
Custom cutting according to client specifications
Surface Grinding/Polishing:
Thickness tolerance: -0 to +0.1mm
Flatness: 0.01/100mm
Surface roughness: Ra ≤1.6 or Rz ≤6.3
Chemical composition %
| C | Si | Mn | P | S | Cr | Mo | W | V | Co |
| 0.35 – 0.45 | 0.15 – 0.5 | 0.2 – 0.5 | max 0.03 | max 0.02 | 4 – 4.7 | 0.3 – 0.5 | 3.8 – 4.5 | 1.7 – 2.1 | 4 – 4.5 |
Mechanical properties
| Brinell hardness (HB): (+A) | 260 |
Equivalent grades
| EU EN | Japan JIS |
| 38CrCoWV18-17-17 | SKD8 |
We can provide more services:
1、Hardening and tempering
2、Vacuum heat treatment
3、Polished bright surface
4、Milling bright surface
5、CNC machine
6、Deep drilling
7、Cut into small pieces
8、Make it closer to the mold
Welcome to inquiry price from drawing
